Furuno FAX30 Navnet Black Box Weather Fax
Furuno's new FAX30 can turn any NavNet display or PC into a Weatherfax and Navtex receiver. This waterproof "Black Box " unit connects directly to a NavNet display or an Ethernet hub with a single Ethernet cable. If it is connected to an Ethernet hub that has multiple 10.4 in NavNet displays attached, each of those displays will have access to the FAX30. In addition, the FAX30 has the capability of being connected to a standard PC with Ethernet card.
The unit itself receives valuable weather images and navigational information. When connected to a 10.4 in NavNet display, the image and information is displayed directly on screen, with softkey menu options for ease of use. On a PC, the images and information are displayed by simply using your Web Browser. There is no complicated proprietary software to install or learn. You can even print all of the information using your PC and printer!
Combine the new FAX30 with NavNet's true color Radar and you have the ultimate in weather tracking. Now you can navigate more safely even during uncertain conditions
Cost effective paperless weatherfax and Navtex receiver
Connect directly to a 10.4 in NavNet display or through an Ethernet hub
Connect to a generic PC equipped with Ethernet
Selectable display colors: 8 gray tones, monochrome, blue shades, pink and black, red and blue
User friendly softkey menu operation on NavNet display
Web browser navigation on generic PC, no proprietary software required
Print images and messages from generic PC and printer
Store a maximum of 12 weatherfax images (depending on file size)
Navtex messages can be retrieved in a table listing of up to 130 stored files
Stored images/messages can be shown at any time
320 user programmed channels
Noise rejection for clear image
Thumbnail view for easy selection of stored images
Phase and synchronization adjustments even after completed reception
Fax Frequency Range:
LF - 80 kHz to 160 kHz
MF/HF - 2 MHz to 25 MHz
Navtex Frequency Range:
490 kHz or 518 kHz
1,000 channels
Fax Mode of Reception:
F3C, J3C
Navtex Mode of Reception: F1B
Waterproof - IEC 60529
Power Requirements 12-24 VDC, 15 W Max.
