Home > Lumishore EOS TIX404 Interchangeable Thru-Hull Mount RGBW LED

Lumishore EOS TIX404 Interchangeable Thru-Hull Mount RGBW LED

$2,569.99
Lumishore
LMS0100452900
Add to Cart

Lumishore EOS TIX404 Interchangeable Thru-Hull Mount RGBW LED

Model: EOS TIX404 / 010-04529-00

The fully controllable color change TIX404 underwater light delivers the greatest range of colors and offers a powerful 7,500 verified fixture lumens and an ultra-wide 110 deg beam angle for the ultimate halo-effect.

Control colors, modes & special effects directly from your MFD and/or the optional Lumishore Display.

All Lumishore Thru-Hulls are 'flush-fit' with extremely low profiles, suitable for transom, side and bottom mounting. TIX models have the added benefit of an internal LED array and integrated driver, for the ability to service from inside the hull and to simplify installation.

Specifications
AVAILABLE LED COLORS
EOS FULL COLOR CHANGE
LUMENS16,875
VERIFIED FIXTURE LUMENS (WHITE)7,500
NUMBER AND TYPE OF LEDWhite-12×10W / Green-12×3W / Blue-12×3W / Red-16×3W
LED POWER - HICOB ARRAYYES
TYPICAL LED LIFE50,000+ HOURS
BEAM ANGLE (DEGREES)110 deg
DRIVERMulti-Channel Internal Driver
SUPPLY VOLTAGE12/24 V DC
MAX CURRENT DRAW (12/24)5.8/2.9A
HOUSING TYPEMARINE GRADE ALUMINUM BRONZE
USER CONTROL OPTIONSFrom your MFD and/or optional Lumishore Display
LIGHTS SYNCHRONIZEDYES
COLOR CYCLEYES
COLOR CYCLE w/SPEED ADJUSTYES
COLOR SWEEP w/SPEED ADJUSTYES
CUSTOMIZABLE FAVORITESYES
FIXED STROBE (2-Speed)YES
WI-FI CONTROL (APP)YES
SOUND-TO-LIGHTYES
BRIGHTNESS ADJUSTYES
AUTO LIGHT DISCOVERY & SETUPYES
WARRANTY3 YEARS

What's in the Box:
  • One (1) EOS TIX404 Light with Built-in Driver
